Specification

• CPU Support : LGA1151 socket : Support intel Core i3,i5,i7 and Celeron, Pentium series 6,7,8,9 generation processors
• Chipset : Intel H110
• Memory : Supports Dual Channel DDR4 2133/2400/2666MHz The maximum memory capacity is 32GB
• Graphics : Support graphics card types are PCI-E2.0 x16 interface *Graphics specifications may vary between CPU types Please refer to www.intel.com for any updates
• Audio : HD AUDIO Audio chip with 3-channel output
• LAN : 1x Realtek 1000M/bps LAN controller
• Storage Interface : 3*SATA 3.0, 1*M.2 INTERFACE, 1*PCI-E 16X, 2*DDR4 Memory Slot
• USB : 4*USB2.0, 1*USB3.0 PIN, 2*USB3.0, 1*USB2.0 PIN
• Internal I/O Connectors : 1*24 PIN Power Supply, 1*Audio PIN, 1*4 PIN PWR
• Back Panel Connectors : 2*USB2.0, 1*Audio, 1*HDMI, 2*USB2.0, 1*VGA, 2*USB3.0, 1*LAN
• H/W Monitoring : CPU/System temperature detection, CPU/System/Power fan speed detection, System voltage detection
• BIOS : Authorized AMI BIOS
• Form Factor : Micro ATX 170*190MM
